Flutter를 4년만에 다시 시작한 것 치고는 별 문제없이 UX, 개발, 테스트를 동시에 진행하며 개발을 완료했다. 2주 동안 개발하는 내내 몰입하는 즐거움을 느꼈다. 개발에 특별히 엄청난 기술이 들어가지는 않았다. Realm과 Table calendar를 써 본 정도다. 선언형 UI 개발 방식이 명령형 방식보다 개발하기 더 좋은 느낌이다. 느낌이지 확실한 결론은 아니다. 개발 속도도 빠른 것 같고, 적어도 버그의 개수는 줄어들것 같다. 소스코드를 저장만 해도 동작중인 앱에 반영이 되는 것은 큰 장점이다. 그리고 역시나 네이티브를 잘 알고 있는 것이 중요한 것 같다. 플러그인 없이는 괜찮은 기능을 만들기 어렵다.
22년 6월 부터 사실상 놀고 있다. 이 블로그의 글도 거의 업데이트 하지 않고 있다. 업데이트 하지 않는다는 것은 개발도 하지 않고 있다는 뜻이다. 내가 퇴사한 이유도 근본 원인은 번아웃인데 이게 참 무섭다. 아무것도 하지 않고 몇 달을 지낸적도 있다. 나는 개발이 하고 싶어질 때 까지 계속 기다렸다. 23년도가 2달 남은 최근에서야 잠들기 전에 머리속에서 뭔가가 계속 멤돈다. 플러터를 다시 해야겠다는 생각과 몇 년간 독푸딩하고 있는 앱을 결국에는 출시를 해야한다는 생각이다. 두 가지는 확고한 결심이다.
완벽주의 성향이 있는 나로써는 뭔가가 충분히 준비되지 않으면 시작하지 못하는 문제가 있다. 안 좋은 습관이다. Flutter 공부도 시작도 전에 계속 뭔가 그럴듯한 앱을 만들 생각부터 했다. 공부도 되고 또 나와 다른 사람에게 유용한 제품도 되는 것을 찾다보니 뭘 만들지 결정하지 못하고 그래서 시작하지 못하는 것 같다. 그러다 오늘 그냥 시작했다. 계산기나 메모장, 체크리스트, 알람 앱 등을 생각하다가 결국에는 뽀모도로라는 것을 만들기로 했다. 내가 매일 쓸 것 같고, 요구사항이 간단하고, 서버가 필요없고, 글로벌로 런칭할 수 있기 때문에 이게 적당해 보인다.
오늘 3시간 동안 가칭 "내가 만든 뽀모도로"라는 앱을 만들었고 가장 최소한의 기능만 구현하여 폰에 설치하며 독푸딩해봤다. 오랜만이라 오피셜 문서 위주로 다시 들여다 봐야했다. 릴리스 모드 apk가 18메가라니.. 이건 어쩔수 없나보다.
요구사항 - 시작버튼을 누르면 25분 타이머가 시작된다. 시간은 붉은 색으로 표시된다. - 25분이 지나면 소리가 나고 5분 타이머가 시작된다. 시간표시는 검정색으로 바뀐다. - 5분이 지나면 또 다시 다른 소리가 나고, 다시 25분 타이머가 시작된다. - 타이머가 동작중에는 화면이 꺼지지 않는다. - 종료버튼을 누르면 대기 상태가 되고, 대기시간이 지나면 화면도 꺼진다. 이 요구사항이 기본 생성 코드에서 40줄 정도 추가하거나 수정하니 잘 동작했다.
wav파일 재생을 위해서 audioplayers 플러그인을 사용했고, 화면 잠기지 않도록 wakelock 플러그인을 사용했다.
이전에 구글 독스에서 언어를 관리하고 편집하고, 툴을 이용해서 xlsx를 내려받아서 안드로이드의 res/values/strings.xml 파일을 자동으로 생성하는 툴(자바 스크립트)을 개발했었다. 이렇게 하는 이유는 언어 번역과 개발 적용을 분리하기 위해서이고, 번역자는 안드로이드 고유의 포맷 문자열 처리등의 개발 지식이 없더라도 쉽게 수정할 수 있는 방법이 필요했기 때문이다. 때문에 문자열에 ' " ${str} ${num} 과 사용자 친화적인 문자열로 입력하면 되고, 툴은 최종적으로 \' \" %s %d 와 같은 문자열로 치환하여 적용한다.
이게 자바스크립트로 구현했는데 맥 미니에서 동작이 잘 안 되고 (오류를 수정할 수는 있겠지만 귀찮다. node버전과 관련이 있는듯.) 옛날에 Go 언어로 간단한 거 만든적 있고, 파이선도 해 봤지만 문법이 기억나지 않는다. 새로 뭔가를 배워야 한다면 dart 언어로 해 보면 어떨까 싶어서 새로 구현했다. Flutter도 어차피 공부해야해서 언어에 익숙해지는데 도움이 될 듯.
필요한 라이브러리 추가 xml, excel excel 최신버전은 xml 최신 버전과 충돌이 있기 때문에 xml의 버전을 5.4.1 로 다운그레이드한다.
cd lt_lang_utils
dart pub add xml
dart pub add excel
스크린 샷 사용자가 ar-strings.xml 파일을 번역해 왔는데 이 파일은 Google doc로 해당 Row에 맞게 올라가야지 나중에 관리가 된다. 따라서 일단 이것을 같은 Row에 해당 스트링을 찾아서 옆에 ar 스트링을 자동으로 입력하고 그것을 output.xlsx로 만들어서 구글 독스로 붙여넣기를 하기로 했다.
import 'dart:io';
import 'package:xml/xml.dart';
import 'package:excel/excel.dart';
// 안드로이드 strings.xml 에서 <string name="ok">OK</string> ok-> OK 의 map을 만들어 리턴한다.
Map<String, String> loadStringsXml(String filename) {
final Map<String, String> map = {};
final file = File(filename);
final document = XmlDocument.parse(file.readAsStringSync());
final resources = document.getElement('resources')!;
for (var node in resources.children) {
final key = node.getAttribute('name');
if (key?.isNotEmpty == true) {
final text = node.text;
map.putIfAbsent(key!, () => text);
}
}
return map;
}
void writeXlsxFromStringsXml() {
final Map<String, String> arStringMap = loadStringsXml('ar-strings.xml');
final outputExcel = Excel.createExcel();
final outputSheet = outputExcel['Sheet1']; // default sheet
var file = "Screenshot_touch_translation.xlsx";
var bytes = File(file).readAsBytesSync();
var excel = Excel.decodeBytes(bytes);
//Screenshot_touch_translation has below datas
//flutter: [Data([common], 0, 7, null, sheet1), null, null, null, null, null, null, null, null, null, null]
//flutter: [Data(ok, 0, 8, null, sheet1), null, null, null, Data(OK, 4, 8, null, sheet1), Data(확인, 5, 8, null, sheet1), Data(ОК, 6, 8, null, sheet1), Data(OK, 7, 8, null, sheet1), Data(TAMAM, 8, 8, null, sheet1), null, Data(Aceptar, 10, 8, null, sheet1)]
//flutter: [Data(cancel, 0, 9, null, sheet1), null, null, null, Data(Cancel, 4, 9, null, sheet1), Data(취소, 5, 9, null, sheet1), Data(Отмена, 6, 9, null, sheet1), Data(Abbrechen, 7, 9, null, sheet1), Data(Vazgeç, 8, 9, null, sheet1), null, Data(Cancelar, 10, 9, null, sheet1)]
var skipRow = true;
for (var table in excel.tables.keys) {
print(table); //sheet Name
final t = excel.tables[table]!;
print(t.maxCols);
print(t.maxRows);
for (var row in t.rows) {
final keyData = row.elementAt(0);
if (keyData == null ) continue;
final key = keyData.value.toString();
if (key == "[common]" || key == "[app]") {
skipRow = false;
continue;
}
if (skipRow) continue;
final valueData = row.elementAt(4);
if (valueData == null) continue;
final value = valueData.value.toString();
int rowIndex = keyData.rowIndex;
outputSheet.updateCell(CellIndex.indexByColumnRow(columnIndex: 0, rowIndex: rowIndex), key);
outputSheet.updateCell(CellIndex.indexByColumnRow(columnIndex: 1, rowIndex: rowIndex), value);
if (arStringMap.containsKey(key)) {
String? arValue = arStringMap[key];
outputSheet.updateCell(CellIndex.indexByColumnRow(columnIndex: 2, rowIndex: rowIndex), arValue);
} else {
// string-ar/ value not exists.
print("$key-> $value");
}
}
} //for
// save result excel
var fileBytes = outputExcel.save()!;
File("output.xlsx")
..createSync(recursive: true)
..writeAsBytesSync(fileBytes);
print("save OK");
}
두 번째 구글 독스에서 xlsx를 내려받아서 res/values-XX에 strings.xml 파일을 자동으로 만드는 코드다.
class StringItem {
String key;
String text;
StringItem({required this.key, required this.text});
}
void writeStringsFromXlsx() {
var file = "Screenshot_touch_translation.xlsx";
var bytes = File(file).readAsBytesSync();
var excel = Excel.decodeBytes(bytes);
// first table
final t = excel.tables["sheet1"]!;
print(t.maxCols);
print(t.maxRows);
const langRow = 6;
const firstLangCol = 4;
const maxLangColumn = 10; //ar
int column = firstLangCol;
while(column <= maxLangColumn) {
var data = t.cell(CellIndex.indexByColumnRow(columnIndex:column, rowIndex:langRow));
String langCode = data.value.toString();
print("langCode=$langCode");
List<StringItem> baseStringList = List.empty(growable: true);
List<StringItem> appStringList = List.empty(growable: true);
int state = 0;
for (var row in t.rows) {
final keyData = row.elementAt(0);
if (keyData == null) continue;
final key = keyData.value.toString();
if (key == "[common]") {
state = 1;
continue;
}
if (key == "[app]") {
state = 2;
continue;
}
if (key == "--end--") {
break;
}
if (state == 0) continue;
final valueData = row.elementAt(column);
if (valueData == null) continue;
final value = valueData.value.toString();
// 반드시 포함 되어야 하는 데이타 체크
final includeData = row.elementAt(3);
if (includeData != null) {
String includeStrings = includeData.value.toString();
if (includeStrings.isNotEmpty) {
for(var inc in includeStrings.split(' ')) {
if (!value.contains(inc)) {
print("ERROR: $langCode $key $inc $value");
}
}
}
}
if (state == 1) {
baseStringList.add(StringItem(key: key, text: value));
} else {
appStringList.add(StringItem(key: key, text: value));
}
}
writeStringsXml(baseStringList, appStringList, langCode);
column ++;
}
} // for
// 안드로이드 res 폴더에 strings.xml 파일을 생성합니다.
void writeStringsXml(List<StringItem> baseStringList, List<StringItem> appStringList, String langCode) {
String langCodeSuffix;
if (langCode == "en") {
langCodeSuffix = "";
}else {
langCodeSuffix = "-$langCode";
}
final appResdir = "../../screenshot/app/src/main/res/values$langCodeSuffix";
final baseResdir = "../../screenshot/android_base/res/values$langCodeSuffix";
// android_base
{
final builder = XmlBuilder();
builder.processing('xml', 'version="1.0" encoding="UTF-8"');
builder.element("resources", nest: () {
for (var element in baseStringList) {
builder.element("string", nest: () {
builder.attribute("name", element.key);
final newText = touchText(langCode, element.key, element.text);
if (element.key.endsWith("_cdata")) {
builder.cdata(newText);
} else {
builder.text(newText);
}
});
}
});
//
final document = builder.buildDocument();
String xmlString = document.toXmlString(pretty: true, indent: ' ', newLine: '\n');
String path = "$baseResdir/strings.xml";
File(path).writeAsStringSync(xmlString);
print(path);
}
// app
{
final builder = XmlBuilder();
builder.processing('xml', 'version="1.0" encoding="UTF-8"');
builder.element("resources", nest: () {
for (var element in appStringList) {
builder.element("string", nest: () {
builder.attribute("name", element.key);
final newText = touchText(langCode, element.key, element.text);
if (element.key.endsWith("_cdata")) {
builder.cdata(newText);
} else {
builder.text(newText);
}
});
}
});
//
final document = builder.buildDocument();
String newLine = langCode == "en" ? "\r\n" : "\n";
String xmlString = document.toXmlString(pretty: true, indent: ' ', newLine: newLine);
String path = "$appResdir/strings.xml";
File(path).writeAsStringSync(xmlString);
print(path);
}
}
String touchText(String langCode, String key, String text) {
Map<String, String> replaceMap = {};
replaceMap["\${num}"] = "%d";
replaceMap["\${str}"] = "%s";
replaceMap["\${num1}"] = "%1\$d";
replaceMap["\${num2}"] = "%2\$d";
replaceMap["\${num3}"] = "%3\$d";
replaceMap["\${num4}"] = "%4\$d";
replaceMap["\${str1}"] = "%1\$s";
replaceMap["\${str2}"] = "%2\$s";
replaceMap["\${str3}"] = "%3\$s";
replaceMap["\${str4}"] = "%4\$s";
replaceMap["'"] = "\\'";
replaceMap['"'] = '\\"';
if (langCode != "ar") {
replaceMap["\n"] = "\\n";
}
if (text.contains("\r\n")) {
text = text.replaceAll("\r\n", "\\n");
}
if (key.endsWith("_cdata") == false && text.contains("%")) {
text = text.replaceAll("%", "%%");
}
replaceMap.forEach((key, value) {
if (text.contains(key)) {
text = text.replaceAll(key, value);
}
});
return text;
}
실행해 보기
curl -Ls https://docs.google.com/spreadsheets/d/blabla/export\?format\=xlsx > Screenshot_touch_translation.xlsx
dart run lt_lang_utils.dart
좀 있다가 log를 보면 마지막에 초기화를 위한 접속 url을 확인할 수 있다. 그곳으로 접속한다.
[opc@instance-20221029-2034 youtrack]$ docker logs --tail 10 youtrack_youtrack_1
* JetBrains YouTrack 2022.2 runtime environment is successfully configured
* Loading logging configuration from /opt/youtrack/lib/ext/log4j.xml
* Redirecting JetBrains YouTrack 2022.2 logging to /opt/youtrack/logs/internal/services/bundleProcess
* Configuring Service-Container[bundleProcess]
* Configuring Bundle Backend Service
* Configuring Configuration Wizard
* Starting Service-Container[bundleProcess]
* Starting Bundle Backend Service
* Starting Configuration Wizard
* JetBrains YouTrack 2022.2 Configuration Wizard will listen inside container on {0.0.0.0:8080}/ after start and can be accessed by URL [http://<put-your-docker-HOST-name-here>:<put-host-port-mapped-to-container-port-8080-here>//?wizard_token=BlablaToken]
오라클 network에 80과 443은 열어두었다. youtrack은 443으로 연결되지만 프로토콜은 http 이다. 따라서 http://<YOUR_IP or DOMAIN>:443//?wizard_token=BlablaToken 으로 접속한다.
사이트는 열리고 초기화 페이지가 진행되고 YouTrack Configurator 와 Hub는 실행이 되는데 YouTrack은 실행중 오류가 난다. 이유는 모르겠다. 2022.3 버전 과 2022.2 버전 모두 에러가 나고 /mnt/djkim 폴더를 연결하지 않아도 에러가 난다.. 내부 오류 같은데.. 문제 해결 아직 못함.. 서버 로그를 봐도 나오지 않는다. 자바 기반이라 좀 무거운 것 같은데. 그래서 OOM이라도 난 건가
구글 클라우드에서 운영중인 독푸딩 서비스가 있다. 도커를 모를 때라 서버에 필요한 프로그램을 한땀한땀 스크립트를 찾아가면서 설치를 했다. 오라클 클라우드로 API 서버와 DB서버를 이전하면서 도커를 이용했다. 도커만 설치되어 있다면 서버 프로그램을 간단히 실행하고 종료시킬 수 있게 되었다.
GCP 접속하여 Mongo 백업
# ssh 접속
dajkim76@Kims-Mac-mini ~/backend/gcp % ssh -i gcp.key 34.170.xxx.yyy
Enter passphrase for key 'gcp.key':
# mongo 백업
dajkim76@base-backend-1:~$ mongodump --db prod-db --out mongo_221122
# 폴더 압축
dajkim76@base-backend-1:~$ tar cvzf mongo_221122.tar.gz mongo_221122/
dajkim76@base-backend-1:~$ ls -al mongo_221122.tar.gz
-rw-rw-r-- 1 dajkim76 dajkim76 288717 Nov 21 15:45 mongo_221122.tar.gz
압축파일 가져오기
dajkim76@Kims-Mac-mini ~/backend/gcp % sftp -i gcp.key 34.170.xxx.yyy
Enter passphrase for key 'gcp.key':
Connected to 34.170.xxx.yyy.
sftp> get mongo_221122.tar.gz
Fetching /home/dajkim76/mongo_221122.tar.gz to mongo_221122.tar.gz
/home/dajkim76/mongo_221122.tar.gz 100% 282KB 280.5KB/s 00:01
sftp> exit
압축파일 오라클 vm에 업로드
dajkim76@Kims-Mac-mini ~/backend/oci % sftp -i oracle.key opc@132.145.xxx.yyy
Enter passphrase for key 'oracle.key':
Connected to 132.145.xxx.yyy.
sftp> put mongo_221122.tar.gz
Uploading mongo_221122.tar.gz to /home/opc/mongo_221122.tar.gz
mongo_221122.tar.gz 100% 282KB 2.8MB/s 00:00
sftp> exit
압축풀기
[opc@instance-20221029-2034 ~]$ tar xvzf mongo_221122.tar.gz
mongo 도커 컨테이너에 접속하여 db 복구하기
# 컨테이너 접속
docker exec -it docker_mongo_1 bash
# Mongo 복구: 호스트의 mongo_221122 디렉토리의 상위 폴더를 volumes에 바인딩시킬것
mongorestore -u root -p example ./mongo_221122
# 몽고 쉘 접속
mongosh -u root -p example
# 프로덕션 db에 유저 생성
use prod-db
db.createUser( { user: "prod-user", pwd: "prod-pwd", roles: [ { role: "readWrite", db: "prod-db" }, ] } )
이전에 오라클 클라우드에서 로드 밸런서에서 deno 웹 서버까지 연결 테스트 했다. mongo를 docker 켄테이너로 설치하고 deno 서버에서 mongo 서버로 connect까지 해 본다.
50GB volume을 /mnt/djkim 에 마운트했다.
이미 오라클 vm에 자체 block volume을 붙여놓았다. 50GB 용량을 가지고 있고, 이것은 어떤 VM에도 attach될 수 있다. 나중에 vm이 업그레이드 될 경우에도 block volume을 붙이면 데이타 그대로 유지된다. 현재는 mongo db의 저장소로 사용할 예정이다.
[opc@instance-20221029-2034 deno_service]$ docker-compose up -d
Starting deno_service_deno_1 ... done
[opc@instance-20221029-2034 deno_service]$ sudo docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
eccd20973e1f mongo:6.0.2 "docker-entrypoint.s…" 19 minutes ago Up 18 minutes 0.0.0.0:27017->27017/tcp, :::27017->27017/tcp mongo_mongo_1
c9a0b542887a nginx:1.21.6 "/docker-entrypoint.…" 2 days ago Up 2 days 0.0.0.0:80->80/tcp, :::80->80/tcp nginx_nginx_1
42b92c017ed8 denoland/deno:1.28.0 "/tini -- docker-ent…" 2 days ago Up 12 seconds 0.0.0.0:8080->8080/tcp, :::8080->8080/tcp deno_service_deno_1
[opc@instance-20221029-2034 deno_service]$ sudo docker logs --tail 10 deno_service_deno_1
Download https://deno.land/x/web_bson@v0.2.5/src/validate_utf8.ts
Download https://deno.land/x/web_bson@v0.2.5/src/float_parser.ts
Download https://deno.land/x/mongo@v0.31.1/src/utils/saslprep/deps.ts
Download https://deno.land/x/mongo@v0.31.1/src/utils/saslprep/load_code_points.ts
Download https://deno.land/x/mongo@v0.31.1/src/utils/saslprep/sparse_bitfield.ts
Download https://deno.land/x/mongo@v0.31.1/src/utils/saslprep/memory_pager.ts
mongodb connecting ...
mongodb connected OK
HTTP webserver running. Access it at: http://localhost:8080/
Listening on http://localhost:8080/
mongodb connected OK가 찍힌걸로 봐서 연결까지 된 듯 하다.
mongodb://root:example@mongo-host:27017 로 연결은 된 듯 하지만 실제로 읽기나 쓰기를 하면 auth 에러가 날 것이다. test-db에 권한이 없다고 나올 텐데 권한을 추가하자.. https://dajkim76.tistory.com/560 참고
[opc@instance-20221029-2034 deno_service]$ docker ps
CONTAINER ID IMAGE COMMAND CREATED STATUS PORTS NAMES
eccd20973e1f mongo:6.0.2 "docker-entrypoint.s…" 46 minutes ago Up 46 minutes 0.0.0.0:27017->27017/tcp, :::27017->27017/tcp mongo_mongo_1
c9a0b542887a nginx:1.21.6 "/docker-entrypoint.…" 2 days ago Up 2 days 0.0.0.0:80->80/tcp, :::80->80/tcp nginx_nginx_1
42b92c017ed8 denoland/deno:1.28.0 "/tini -- docker-ent…" 2 days ago Up 27 minutes 0.0.0.0:8080->8080/tcp, :::8080->8080/tcp deno_service_deno_1
[opc@instance-20221029-2034 deno_service]$ docker exec -it mongo_mongo_1 bash
root@mongo-host:/app# mongosh -u root -p example
Current Mongosh Log ID: 63765dee3755cc7187c2c247
Connecting to: mongodb://<credentials>@127.0.0.1:27017/?directConnection=true&serverSelectionTimeoutMS=2000&appName=mongosh+1.6.0
Using MongoDB: 6.0.2
Using Mongosh: 1.6.0
For mongosh info see: https://docs.mongodb.com/mongodb-shell/
------
The server generated these startup warnings when booting
2022-11-17T15:25:14.257+00:00: /sys/kernel/mm/transparent_hugepage/enabled is 'always'. We suggest setting it to 'never'
2022-11-17T15:25:14.257+00:00: vm.max_map_count is too low
------
------
Enable MongoDB's free cloud-based monitoring service, which will then receive and display
metrics about your deployment (disk utilization, CPU, operation statistics, etc).
The monitoring data will be available on a MongoDB website with a unique URL accessible to you
and anyone you share the URL with. MongoDB may use this information to make product
improvements and to suggest MongoDB products and deployment options to you.
To enable free monitoring, run the following command: db.enableFreeMonitoring()
To permanently disable this reminder, run the following command: db.disableFreeMonitoring()
------
test> use test-db
switched to db test-db
test-db> db.createUser( { user: "testuser", pwd: "testpwd", roles: [ { role: "readWrite", db: "test-db" }, ] } )
{ ok: 1 }
test-db>
이제 mongodb://testuser:testpwd@mongo-host:27017 로 다시 연결을 만들고 read/write를 해보면 문제 없다. 테스트 해보지는 않았지만 아마도 될 듯.
테스트해 보자.. mongosh로 데이타를 하나 넣었다..
test> use test-db
switched to db test-db
test-db> db.user_list.insertOne({name:"name1", age:31})
{
acknowledged: true,
insertedId: ObjectId("63766d72b310e7e91006854b")
}
test-db>
실행 [opc@instance-20221029-2034 deno_service]$ docker-compose up -d Starting deno_service_deno_1 ... done
결과
dajkim76@Kims-Mac-mini ~ % curl https://oci.mdiwebma.com/deno-app
Your user-agent is:
[{"_id":"63766d72b310e7e91006854b","name":"name1","age":31}]
curl/7.79.1
https://oci.mdiwebma.com/deno-app. 누르면 오라클 클라우드 로드밸랜서 -> VM Nginx -> Deno app 서버 -> mongo db 순으로 요청 흐름이 발생하고 test-db의 user_list 콜렉션을 전부 가져와서 응답한다. nginx, deno, mongo는 모두 docker container로 동작한다.
